Product characteristics

PPSU Fittings are made from special polymer - polyphenyl sulfone (PPSU).

Using PPSU pipe fittings to connect with PEX pipes are characterized by high impact strength, high temperatureresistance ( up to +170^C ) and exposure to aggressive environments. Like other plastic products, PPSU is not subjectto corrosion. PPSU compounds are also UV resistant and sediments of mineral substances dissolved in water.

Maximum allowable working pressure: 10 bar;

Test pressure:16 bar;

Maximum permissible temperature of the transported medium: 95℃

Service Life: 50 years

Melting point: +170 ℃

Pipe Dimensions to connect: 16*1.8,20*1.9,25*2.3 & 32*2.9mm

Product Execution Standards
